BV DIAMOND TOOL CO.,LTD
Specifications
*Arbour Hole: 25.40mm (1'')
*Pin Hole: 12mm
Advantages:
1.Saw blade use high quality blank.
2.Diamond segment use high quality emery and special mixture.
3.Our Saw blade is very sharp, high efficiency and stable performance.
4.fast cutting speed without chipping.
5.Mature production process.
6.Strict product quality inspection processes.
7.Rapid delivery process.
8.Perfect after-sale service, if you has any problem, contact us anytime.
| Out diameter(mm) | Segment Leght | Thickness | Height | No.of teeth |
| 250 | 40 | 2.6/2.8 | 8/10/12 | 17 |
| 300 | 40 | 2.8/30 | 8/10/12 | 21 |
| 350 | 40 | 3.0/3.2 | 8/10/12 | 24 |
| 400 | 40 | 3.4/3.6 | 8/10/12 | 28 |
| 450 | 40 | 3.8/4.2 | 8/10/12 | 32 |
| 500 | 40 | 4.0/4.2 | 8/10/12 | 36 |
| 600 | 40 | 4.6/4.8 | 8/10/12 | 40 |
| 650 | 40 | 4.6/4.8 | 8/10/12 | 42 |
| 700 | 40 | 5.0/5.2 | 8/10/12 | 50 |
| 750 | 40 | 5.2/5.6 | 8/10/12 | 54 |
| 800 | 40 | 5.5/6.0 | 8/10/12 | 57 |
*Other specifications are available upon request.
